Product benefits

• Maximum flow rate for maximum efficiency: With up to 40 litres per minute via the jet regulator, the single-lever mixer 40L-1801B is ideal for smooth operations in commercial kitchens and where high water demand is required.
• Robust for daily heavy use: Full metal construction with heat and pressure-resistant 150 kg hose – designed for long-term reliability in professional kitchen environments.
• Precise control unit thanks to high-performance cartridge: Durable ceramic disc technology ensures consistent mixing accuracy and minimises maintenance – even with intensive use.
• Optimised rinsing function for time-saving work: The lockable sieve spray with closing delay and non-return valve enables controlled water release when cleaning dishes and Containers.
• Integrated, reliable backflow protection: The built-in backflow preventer reliably protects the pipe system from contamination – for maximum hygiene at the Water connection.
• Perfectly adaptable thanks to flexible regulation: The water pressure can be individually adjusted to suit the work process and equipment used using an adjustment screw – directly on the fitting.

Technical data

• Width: 65 mm
• Depth: 450 mm
• Height: 1540 mm
• Net weight: 8.5 kg
• Gross weight: 9.1999999999999993 kg
• Volume: 0.018 MTQ
• Guarantee: VG
• Customs tariff number: 84818011
• Flow at 3 bar: Shower arm: 18 L / min. ,Jet regulator: 40 L / min.
• Valve type: High-performance cartridge with ceramic washer equipment
• Assembly type: Single-hole borehole ,Screw system
• Design: Mixer tap with dishwashing shower arm
• Properties: Replaceable sieve ,Spring mechanism ,Rubber stopper ring ,No chrome-damage by additional hard-nickel coating ,Check valve ,No recoil thanks to blockable screen-shower head with closing delay ,Hose can be loaded up to 150 kg, hot water resistant, pressure resistant ,Stuffing box seals ,Full metal ,Water pressure can be regulated with a setting strong
• Swivelling outlet: 180°
• Installation: Copper pipe connection 15 mm
• Diameter table borehole: 42 mm
• Jet regulator mouthpiece: M22
• Material: Chrome-plated
• Fitting type: Single lever mixer
• Handles: Chrome ,Thermally insulated

Documents

• Datasheet
• Operating instructions
• Exploded view

Manufacturer item number: 400123
