Gas tilting frying pan G80LHK, 70-litre capacity, 798 mm pan width, 22 kW, piezo ignition, safety system with thermocouple. Water connection, manual tilting mechanism, up to 300 °C. For commercial kitchens with medium to high braising volumes using gas.

Product benefits

• Maximum output for the highest demands: With a gas output of 22 kW, the G80LHK tilting frying pan reliably meets every requirement in catering and communal catering, even when large quantities of food are involved.
• Large volume, compact design: 80 litre frying capacity in a single appliance with an ergonomically designed Tilting device – ideal for commercial kitchens with high output and limited space.
• Precise temperature control for perfect cooking results: The wide temperature range from 100 °C to 300 °C allows for the precise preparation of delicate foods as well as the rapid frying of large quantities.
• Stability meets flexibility: Height-adjustable stainless steel feet allow adjustment to a wide range of working heights – for fatigue-free working and optimum ergonomics.
• Safe cooking with sophisticated technology: The integrated safety system with thermocouple, piezo ignition and Pilot flame ensures reliable operation and minimises the risk of failure in everyday kitchen use.
• Robust materials for continuous daily use: The crucible made of high-quality chrome-nickel steel (CNS 18/10) guarantees durability, easy cleaning and hygienic working even with intensive use.
• Flexible gas operation for every kitchen situation: Whether natural gas H or liquid gas – thanks to the 50 mbar nozzles supplied, the G80LHK is ready for immediate use, regardless of the type of gas.
• Built-in water feed for efficient working: With an integrated water supply tap and 12 mm Water connection, cleaning and preparation can be carried out directly on the appliance, saving time.

Technical data

• Width: 900 mm
• Depth: 900 mm
• Height: 900 mm
• Net weight: 162.6 kg
• Gross weight: 191.9 kg
• Volume: 1.771 MTQ
• Guarantee: VG
• Customs tariff number: 84198180
• Height-adjustable to: 910 mm
• Connected load gas: 22 kW
• Material crucible: Chrome-nickel steel
• Useful content: 70 litre(s)
• Tilting device: Manual
• Height crucible: 200 mm
• Ignition type: Piezo ignition
• Water connection: 12 mm
• Temperature range from: 100 °C
• Height-adjustable feet: Yes
• Depth crucible: 570 mm
• Content: 80 litre(s)
• Pilot flame: Yes
• Water supply tap: Yes
• Height-adjustable from: 850 mm
• Material: CNS 18/10
• Operating mode: Gas
• Gas type: Natural gas H ,Liquid gas nozzles (50 mbar) are enclosed
• Temperature range to: 300 °C
• Width crucible: 798 mm
• Properties: Gas heater with stainless steel tube burner ,Safety system with thermal element

Documents

• Datasheet
• Exploded view

Manufacturer item number: 1930311
