The high-performance ice flake males is ideal for presenting food on fresh food counters or buffets.

Product benefits

• High performance for continuous operation: With up to 90 kg of ice flakes per day, the F 90 easily meets the demands of everyday professional kitchen use – ideal for fresh food counters and buffets with high throughput.
• Energy-efficient thanks to modern refrigerant: The environmentally friendly R290 refrigerant ensures efficient and sustainable cooling while reducing energy consumption.
• Space-saving and flexible integration: Can be fitted below the counter and with a standardised water connection, the flake ice maker adapts perfectly to different locations in the kitchen and counter area.
• Optimal hygiene thanks to sophisticated design: CNS 18/10 stainless steel and corrosion-resistant materials ensure hygienic ice production – easy to clean and durable in use.
• Intuitive operation via touch control unit: The modern touch surface enables quick and easy operation even under high workloads and when wearing gloves.
• Reliable control during operation: The filling level sensor, control lamp and ON/OFF switch provide an overview and control at all times – for smooth operation without interruptions.
• Powerful in any environment: Designed for climate class T, the F 90 delivers consistently powerful ice production even at high ambient temperatures – ideal for commercial kitchens and hot application areas.
• Fast water outlet for smooth operation: With a Ø 20 mm drain and easy accessibility, excess water drains efficiently – for clean operating processes and minimised maintenance.

Technical data

• Width: 500 mm
• Depth: 600 mm
• Height: 695 mm
• Net weight: 51.9 kg
• Gross weight: 80.2 kg
• Volume: 1.075 MTQ
• Guarantee: VG
• Customs tariff number: 84186900
• Control lamp: yes
• Filling level sensor: Yes
• Colour: Silver ,Grey
• Production by means of: Vertical evaporator system
• Coolant: R290 / 0,070 kg
• Can be installed: Yes
• Production max.: 90 kg / 24 h
• ON/OFF switch: Yes
• Power: 0.41 kW
• Control unit: Touch
• Water connection: 3/4"
• Climate class: T
• Voltage: 230 V
• Water outlet: Ø 20 mm
• Frequency: 50 Hz
• Material: CNS 18/10 ,Plastic ,Steel ,Galvanised
• Can be fitted below the counter: Yes
• Storage container capacity: 18 kg
• Cooling: Air cooled
• Including: 1 ice shovel
• Important information: Clearance to all sides at least 15 cm

Documents

• Datasheet
• Operating instructions
• Exploded view
• Wiring diagram

Manufacturer item number: 104609
