Small but fine: Space saving glass display unit for displaying and presenting hot meals.

Product benefits

• Compact heat for high demands: With a power consumption of only 0.5 kW, the R4 delivers efficient heat output – ideal for limited work surfaces in kitchens and counters.
• Optimal visibility – glazed all around: The single-pane all-round glazing with a rounded front presents food attractively from every angle while protecting against heat loss.
• Hygienic serving, easy refilling: Rear sliding doors allow quick access for staff – without compromising on hygiene and heat retention.
• Flexibility in GN format: The integrated holder for 4 x 1/3 GN containers up to 40 mm deep allows for a wide variety of food choices in standardised sizes.
• Robustness meets design: Stainless steel and Safety glass guarantee durability and a professional look – even with frequent use.
• Stepless temperature control for precise dispensing: Temperature individually adjustable from 30 to 90 °C – for perfect keeping warm of a wide variety of foods throughout the entire service period.

Technical data

• Width: 775 mm
• Depth: 420 mm
• Height: 335 mm
• Net weight: 16.2 kg
• Gross weight: 18.25 kg
• Volume: 0.157 MTQ
• Guarantee: VG
• Customs tariff number: 84198180
• Temperature range from: 30 °C
• Control lamp: ON/OFF ,Heat up
• Safety glass: Yes
• Including: GN containers
• Frequency: 50 Hz
• Type of glass: Single glazing ,All-round glass
• Colour: Silver
• Temperature control: Stepless
• Material: Stainless steel ,Glass
• Type of door: Sliding door(s)
• Front pane: Rounded
• Voltage: 230 V
• Power: 0.5 kW
• Water bowl for air humidification: No
• Control unit: Toggle ,Knob
• Capacity GN: 4 x 1/3 GN
• Digital display: No
• Depth GN container max.: 40 mm
• Temperature range to: 90 °C
• Content: 46 litre(s)
• Heating type: Dry heated
• Interior lighting: No
• Position of the door: Reverse

Documents

• Datasheet
• Operating instructions
• Exploded view
• Wiring diagram

Manufacturer item number: 305058
