Hygienic and clean – glass attachment as sneeze guard

Product benefits

• Three sizes, one decision: flexibility: Thanks to selectable hollow cone sizes, the HK150 adapts precisely to every type of drink and guest preference – ideal for a variety of application areas from bars to buffets.
• Ice production without a water connection: The integrated 4.5-litre water tank eliminates the need for a fixed water connection – maximum freedom when placing in counters or mobile stations.
• Compact design for confined workspaces: With its space-saving model, the HK150 fits easily into even small counter spaces – without compromising on performance.
• Efficient even when demand is high: Up to 15 kg of ice in 24 hours ensures a reliable supply – even at peak times, drinks always remain perfectly chilled.
• Overview at a glance: LED control lamps provide information about operational readiness, ice level and water requirements at all times – for smooth operations without surprises.
• Optimised for everyday catering: With automatic ice cube selection, water tank sensors and an air-cooled system, the HK150 is designed for long-term performance and low maintenance.
• Hollow cone for faster cooling: The perforated ice cubes allow for a larger contact surface in the drink – perfect for rapid cooling without diluting the flavour.
• Sustainable with R290 refrigerant: The use of the natural refrigerant R290 combines high energy efficiency with environmentally friendly cooling technology – a plus point for sustainable operation.

Technical data

• Width: 1500 mm
• Depth: 335 mm
• Height: 460 mm
• Net weight: 38.799999999999997 kg
• Gross weight: 57.4 kg
• Volume: 0.277 MTQ
• Guarantee: VG
• Customs tariff number: 84185019
• Height glass top: 195 mm
• Including: 4 bars: length 181 mm, width 25 mm ,6 bars: length 264 mm, width 25 mm
• Frequency: 50 Hz
• Temperature range to: 10 °C
• Climate class: N
• Depth glass top: 330 mm
• Digital display: Yes
• Temperature range from: 0 °C
• Front pane: Turned-down edges
• Automatic defrosting function: Yes
• Delivery state: Building kit (simple assembly)
• Not included in delivery: GN containers
• Control lamp: ON/OFF
• Temperature control: Digital
• Properties: Cooling aggregate with cooling tray
• Material: Chrome-nickel steel ,Glass
• Voltage: 230 V
• Cooling: Static
• Control unit: Electronic ,Knob
• Coolant: R290 / 0,030 kg
• Design: With glass top
• Glass top unit design, back: Open
• Power: 0.174 kW
• Width glass top: 1490 mm
• Type of glass: Single glazing
• ON/OFF switch: Yes
• Safety glass: Yes
• Depth GN container max.: 150 mm
• Capacity GN: 7 x 1/4 GN
• Drip water evaporation: Yes

Documents

• Datasheet
• Operating instructions
• Exploded view
• Wiring diagram
• Documentation

Manufacturer item number: 110272
