Clean and hygienic – a glass top for germ protection

Product benefits

• Maximum output in minimum space: The compact "Mini" conveyor toaster saves space on the buffet and still delivers up to 75 slices of toast per hour – ideal for small areas with high demands.
• Precise control unit for perfect results: Separately adjustable belt speed and heat supply enable optimal adaptation to different products such as rolls, toast or sandwiches.
• Flexible heat options for greater variety: A choice between top and bottom heat for toast and targeted top heat for rolls ensures optimum crust formation – exactly as required for the product.
• Quick start for hectic everyday life: The toaster reaches operating temperature in just 15 to 20 minutes and is immediately ready for use – ideal for fast service in restaurants and catering.
• Robust construction for continuous use: Made from high-quality stainless steel and equipped with sophisticated electronics, the conveyor toaster can withstand even intensive use in professional environments.
• Intuitive operation – even during peak periods: Thanks to an electronic control unit with a rotary knob and a clear on/off control lamp, operation remains straightforward and efficient at all times – even when there are large numbers of guests.

Technical data

• Width: 1500 mm
• Depth: 395 mm
• Height: 460 mm
• Net weight: 45.5 kg
• Gross weight: 61 kg
• Volume: 0.31 MTQ
• Guarantee: VG
• Customs tariff number: 84185019
• Height glass top: 195 mm
• Including: 1 bar: length 326 mm, width 77 mm ,4 bars: length 181 mm, width 25 mm ,6 bars: length 326 mm, width 25 mm
• Frequency: 50 Hz
• Temperature range to: 10 °C
• Climate class: N
• Depth glass top: 390 mm
• Digital display: Yes
• Temperature range from: 0 °C
• Front pane: Turned-down edges
• Automatic defrosting function: Yes
• Delivery state: Building kit (simple assembly)
• Not included in delivery: GN containers
• Control lamp: ON/OFF
• Temperature control: Digital
• Properties: Cooling aggregate with cooling tray
• Material: Chrome-nickel steel ,Glass
• Voltage: 230 V
• Cooling: Static
• Control unit: Electronic ,Knob
• Coolant: R290 / 0,030 kg
• Design: With glass top
• Glass top unit design, back: Open
• Power: 0.174 kW
• Width glass top: 1490 mm
• Type of glass: Single glazing
• ON/OFF switch: Yes
• Safety glass: Yes
• Depth GN container max.: 150 mm
• Capacity GN: 5 x 1/3 GN + 1 x 1/2 GN
• Drip water evaporation: Yes

Documents

• Datasheet
• Operating instructions
• Exploded view
• Wiring diagram

Manufacturer item number: 110276
